Save the current configuration.
15.
exa1sw-ip#copy running-config startup-config
Destination filename [startup-config]?
Building configuration...
Compressed configuration from 2654 bytes to 1189 bytes[OK]
Exit from the session using the following command:
16.
exa1sw-ip#exit
exa1sw-ip con0 is now available
Press RETURN to get started.
Disconnect the cable from the Cisco console.
17.
The Cisco switch must not be connected to the management network at this stage.
The switch will be connected later after Oracle has configured the systems with
the necessary IP addresses and you have worked with the field service engineer
to make any additional changes necessary for connecting to the network.
To check the Cisco swtich, attach a laptop computer to port 48, and ping the IP
18.
address of the Exadata internal management network to check the configuration.
Related Topics:
• Network Connection and IP Address Requirements for Oracle Exadata Database
Machine
• Network Configuration Checklist
Use this checklist to ensure that the network configuration requirements have
been addressed.

5.2.2 Configuring the Cisco Nexus 93108-1G Ethernet Switch

The Cisco Nexus 93108-1G Ethernet switch supplied with Oracle Exadata Rack is
minimally configured during installation.
Whether you are configuring the switch for the first time, or configuring a replacement
switch, use the following procedures:
• Performing the Initial Switch Configuration for the Cisco Nexus 93108-1G Ethernet
Switch
Note:
If any setting is incorrect, the repeat the appropriate step. To erase a setting,
enter in front of the same command. For example, to erase the default
no
gateway, use the following commands:
exa1sw-ip#configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
exa1sw-ip(config)#no ip default-gateway 10.7.7.1
exa1sw-ip(config)#end
exa1sw-ip#
*Sep 15 14:13:26.013: %SYS-5-CONFIG_I: Configured from console by console
exa1sw-ip#write memory
Building configuration...
Compressed configuration from 2502 bytes to 1085 bytes[OK]
(page 1-47)
(page 5-14)
Configuring the Cisco Ethernet Switch
(page A-15)
Chapter 5
5-13
