Oracle EXADATA X6-2 Installation And Configuration Manual page 133

Note:
To change the default names of the administration network, click Modify. After
changing the fields, click Save to save the changes.
Enter the client network information on the Client Ethernet Network page, and click
9.
Next.
Note:
To change the default names of the client network, click Modify. After
changing the fields, click Save to save the changes.
Enter the InfiniBand information on the InfiniBand Network page, and click Next.
10.
Note:
To change the default names of the InfiniBand network, click Modify. After
changing the fields, click Save to save the changes.
(Optional) Enter the backup information on the Backup Network page, and click
11.
Next.
Note:
To change the default names of the backup network, click Modify. After
changing the fields, click Save to save the changes.
Enter the operating system information on the Identify Compute Node Base OS
12.
configuration page, and click Next.
Review, and edit the information for the management and private networks, and
13.
click Next.
Define the clusters on the Define Clusters page for each cluster, and click Next.
14.
Review and edit the cluster information for each cluster, and click Next.
15.
(Optional) Enter the e-mail alert information on the Cell Alerting page, and click
16.
Next.
(Optional) Enter the Oracle Configuration Manager information on the Oracle
17.
Configuration Manager page, and click Next.
(Optional) Enter the Auto Service Request (ASR) information on the Auto Service
18.
Request page, and click Next.
(Optional) Enter the Oracle Enterprise Manager Grid Control information on the
19.
Grid Control Agent page, and click Next.
Chapter 3
OEDA Graphical User Interface
3-6
