Review And Edit Scan, Client, Vip And Optional Backup Networks; Cell Alerting Configuration Page - Oracle EXADATA X6-2 Installation And Configuration Manual

For ACFS Volume Name, accept the default volume name, or enter a new ACFS
6.
volume name.
The volume name must be between 1 and 11 alphanumeric characters, and must
start with an alphabetic character.
For ACFS Volume Size, enter the desired size of the ACFS volume.
7.
For ACFS Mount Point, accept the default mount point, or enter a new ACFS
8.
mount point.
3.2.14 Review and Edit SCAN, Client, VIP and Optional Backup
Networks
Review and update entries for the clusters and client network, then click Re-Generate
Data, and then click Next.

3.2.15 Cell Alerting Configuration Page

Cell alert delivery may be configured during or after installation.
Cell alerts can be delivered using Simple Mail Transfer Protocol (SMTP), Simple
Network Management Protocol (SNMP), or both. The following table lists the cell alert
configuration options.
Table 3-13
Cell Alerting Field
Enable Email Alerting
Recipients Addresses
SMTP Server
Uses SSL
Port
Note:
The domain specified on Customer Details page is used as the domain for all
networks. If different domains are used for the client and backup networks,
then specify those domains on this page.
Cell Alerting Configuration Page
OEDA Graphical User Interface
Description
Enables cell alerts to be delivered
automatically.
Sets the e-mail addresses for the recipients of
the cell alerts. Multiple addresses can be
entered in the dialog box. The number of e-
mail addresses is shown.
Sets the SMTP e-mail server used to send
alert notifications
Example: mail.example.com
Enables Secure Socket Layer (SSL) security
when sending alert notifications.
Sets the SMTP e-mail server port used to
send alert notifications
Example: 25 or 465
Chapter 3
3-24
