Table 1-12

Expansion Rack X4-2

Environmental
Component
Air flow front-to-back
(subject to actual data
center environment)
IP Addresses
Network drops
External connectivity
1.1.15 General Environmental Requirements for Oracle Exadata
Storage Expansion Rack X3-2
The environmental requirements for Oracle Exadata Storage Expansion Rack X3-2
depend on the size of the system.
environmental requirements for each type of Oracle Exadata Storage Expansion Rack
X3-2.
Table 1-13
Rack X3-2
Environmental
Component
Weight
Acoustic levels
(Cont.) Environmental Requirements for Oracle Exadata Storage
Oracle Exadata
Storage Expansion
X4-2 Full Rack
• High performance
drives
Maximum:
Approximately
1,600 CFM
Typical:
Approximately
1,100 CFM
• High capacity
drives
Maximum:
Approximately
1,410 CFM
Typical:
Approximately
980 CFM
42 for Ethernet
network, assuming
single cluster
36 for InfiniBand
network
Minimum of 1 network
drop
12 InfiniBand ports
Table 1-13
Environmental Requirements for Oracle Exadata Storage Expansion
Oracle Exadata
Storage Expansion
X3-2 Full Rack
827.4 kg (1824 lbs)
82 db(A)
General Environmental Requirements
Oracle Exadata Oracle Exadata
Storage Expansion Storage Expansion
X4-2 Half Rack X4-2 Quarter Rack
• High performance •
drives
Maximum:
Approximately
900 CFM
Typical:
Approximately
650 CFM
• High capacity •
drives
Maximum:
Approximately
810 CFM
Typical:
Approximately
570 CFM
24 for Ethernet 13 for Ethernet
network, assuming network, assuming
single cluster single cluster
18 for InfiniBand 8 for InfiniBand
network network
Minimum of 1 network Minimum of 1 network
drop drop
12 InfiniBand ports 12 InfiniBand ports
(page 1-23) shows the general
Oracle Exadata Oracle Exadata
Storage Expansion Storage Expansion
X3-2 Half Rack X3-2 Quarter Rack
516.2 kg (1138 lbs) 349.7 kg (771 lbs)
79 db(A) 76 db(A)
Chapter 1
High performance
drives
Maximum:
Approximately
440 CFM
Typical:
Approximately
310 CFM
High capacity
drives
Maximum:
Approximately
410 CFM
Typical:
Approximately
300 CFM
1-23
