Oracle EXADATA X6-2 Installation And Configuration Manual page 39

Table 1-16 Environmental Requirements for X6-2 Single Servers
Environmental Exadata Storage
Component Server X6-2 -
Extreme Flash
Weight 28.1 kg (62 lbs)
Acoustic levels 78 db(A)
Power Maximum: 0.6 kVA
Typical: 0.4 kVA
(varies based on
application load)
Cooling Maximum: 1,866 BTU/
hour (1,969 kJ/hour)
Typical: 1,307 BTU/
hour (1,378 kJ/hour)
Air flow front-to-back Maximum:
(subject to actual data Approximately 86
center environment) CFM
Typical:
Approximately 60
CFM
Table 1-17 Environmental Requirements for X5-2 Single Servers
Environmental Exadata Storage
Component Server X5-2 -
Extreme Flash
Weight 28.1 kg (62 lbs)
Acoustic levels 78 db(A)
Power Maximum: 0.6 kVA
Typical: 0.4 kVA
(varies based on
application load)
Cooling Maximum: 2,037 BTU/
hour (2,149 kJ/hour)
Typical: 1,426 BTU/
hour (1,504 kJ/hour)
Air flow front-to-back Maximum:
(subject to actual data Approximately 94
center environment) CFM
Typical:
Approximately 66
CFM
General Environmental Requirements
Exadata Storage Database Server
Server X6-2 - High X6-2
Capacity
33.1 kg (73 lbs) 20.4 kg (45 lbs)
78 db(A) 78 db(A)
Maximum: 0.6 kVA Maximum: 0.665 kW
(0.678 kVA)
Typical: 0.4 kVA
(varies based on Typical: 0.466 kW
application load) (0.475 kVA) (varies
based on application
load)
Maximum: 2,006 BTU/ Maximum: 2,269 BTU/
hour (2,117 kJ/hour) hour (2,394 kJ/hour)
Typical: 1,404 BTU/ Typical: 1,588 BTU/
hour (1,482 kJ/hour) hour (1,676 kJ/hour
Maximum: Maximum:
Approximately 93 Approximately 105
CFM CFM
Typical: Typical:
Approximately 65 Approximately 74
CFM CFM
Exadata Storage Database Server
Server X5-2 - High X5-2
Capacity
33.1 kg (73 lbs) 20.4 kg (45 lbs)
78 db(A) 78 db(A)
Maximum: 0.6 kVA Maximum: 0.7 kVA
Typical: 0.4 kVA Typical: 0.5 kVA
(varies based on (varies based on
application load) application load)
Maximum: 2,000 BTU/ Maximum: 2,481 BTU/
hour (2,109 kJ/hour) hour (2,617 kJ/hour)
Typical: 1,400 BTU/ Typical: 1,736 BTU/
hour (1,477 kJ/hour) hour (1,832 kJ/hour
Maximum: Maximum:
Approximately 93 Approximately 115
CFM CFM
Typical: Typical:
Approximately 65 Approximately 80
CFM CFM
Chapter 1
1-27
