Oracle EXADATA X6-2 Installation And Configuration Manual page 224

ip name-server 10.8.160.1
!
ip vrf mgmtVrf
!
vtp mode transparent
!
power redundancy-mode redundant
!
!
spanning-tree mode pvst
spanning-tree extend system-id
!
vlan internal allocation policy ascending
!
interface FastEthernet1
ip vrf forwarding mgmtVrf
no ip address
speed auto
duplex auto
!
interface GigabitEthernet1/1
spanning-tree portfast
!
interface GigabitEthernet1/2
spanning-tree portfast
!
...
!
interface GigabitEthernet1/48
media-type rj45
!
interface Vlan1
ip address 10.7.7.34 255.255.255.0
!
interface Vlan48
no ip address
shutdown
!
ip default-gateway 10.7.7.1
ip http server
!
control-plane
!
line con 0
stopbits 1
line vty 0 4
password welcome1
transport input ssh
line vty 5 15
password welcome1
transport input ssh
!
ntp server 10.7.7.32 prefer
ntp server 198.51.100.19
end
Chapter 5
Configuring the Cisco Ethernet Switch
5-12
