Note that the Cisco 4948E-F switch supports multiple uplinks to the customer network
by utilizing ports 49 - 52. This is a more complicated switch setup due to the redundant
connectivity, and should be performed by the customer's network administrator.
The following procedure describes how to configure the Cisco Ethernet switch.
Configuration should be done with the network administrator.
Connect a serial cable from the Cisco switch console to a laptop or similar device.
1.
An Oracle supplied rollover cable is pre-installed on the Cisco serial console port.
Obtain the appropriate adapter and connect it at the end of the rollover cable. An
Oracle P/N 530-3100 RJ45-DB9 adapter as used on ILOM ports will also work,
connected at the end of the network cable.
Ensure the terminal session is recorded on the laptop by logging the output. The
2.
output can be used as a reference that the switch has been configured correctly.
The default serial port speed is 9600 baud, 8 bits, no parity, 1 stop bit, and no
handshake.
Switch con0 is now available
Press RETURN to get started.
Change to the enable mode.
3.
Switch> enable
Password: ******
Switch#
Note:
If you do not have the password, then contact Oracle Support Services.
Check the current version on the swtich.
4.
Switch# show version
Cisco IOS Software, Catalyst 4500 L3 Switch Software (cat4500e-
IPBASEK9-M), Version 15.2(3)E2, RELEASE SOFTWARE (fc1)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2014 by Cisco Systems, Inc.
Compiled Tue 11-Mar-14 18:28 by prod_rel_team
ROM: 12.2(44r)SG12
zdlra1sw-ip uptime is 1 minute
System returned to ROM by reload
System image file is "bootflash:cat4500e-ipbasek9-mz.152-3.E2.bin"
Hobgoblin Revision 22, Fortooine Revision 1.40
...
Configuration register is 0x2102
Switch#
The version of the Cisco 4948E-F switch firmware purchased and shipped by
Oracle with Exadata Database Machine X6 is IPBASEK9-MZ, which includes
and support. Currently the full release version string is
telnet ssh
ipbasek9-mz.152-3.E2.bin
Configure the network for a single VLAN. The following example assumes you are
5.
using IPv4 addressing.
.
Chapter 5
Configuring the Cisco Ethernet Switch
cat4500e-
5-7
