Table 1-30 (Cont.) Low-voltage 24 kVA Three Phase PDUs for North America,
South America, Japan and Taiwan (2 PDUs per Rack)
Option
Outlets
Outlet groups
Group protection (UL489 2-pole circuit
breaker)
Data center receptacle
The following are needed to connect an Oracle Exadata system to a low-voltage three-
phase power source:
• 4 power cords for two PDUs
• 4 receptacles to connect the PDUs
Table 1-31 (page 1-41) lists the PDU requirements for high-voltage 24 kVA three
phase PDUs. The following specifications are per PDU.
Table 1-31 High-voltage 24 kVA Three Phase PDUs for Europe, the Middle East
and Africa (EMEA), and Asia Pacific (APAC), except for Japan and Taiwan (2
PDUs per Rack)
Option
Voltage
Frequency
Current
Power rating
Output current
Outlets
Outlet groups
Group protection (UL489 1-pole circuit
breaker)
Data center receptacle
The following are needed to connect an Oracle Exadata system to a high-voltage
three-phase power source:
• 4 power cords for two PDUs
• 4 receptacles to connect the PDUs
Table 1-32 (page 1-42) lists the requirements for 37 kVA low-voltage three-phase
PDUs for Oracle Exadata Database Machine X6-8, X5-8, and X4-8 with more than four
database servers. There are two PDUs per rack. The following specifications are per
PDU.
Electrical Power Requirements
Requirement, per PDU
42 x C13; 6 x C19
6
20A
IEC309-3P4W-IP67 60A 250VAC 3ph
(Hubbell equivalent is HBL460R9W)
Requirement, per PDU
220/380 - 240/415 VAC 3-phase
50/60 Hz
18.1 A maximum per phase
25 kVA
108.6A (6 x 18.1 A)
42 x C13; 6 x C19
6
20A
IEC309-4P5W-IP44 32A 400VAC 3ph
(Hubbell equivalent is HBL532R6W)
