Table 1-13
Expansion Rack X3-2
Environmental
Component
IP Addresses
Network drops
External connectivity
1.1.16 General Environmental Requirements for Oracle Exadata
Storage Expansion Rack with Exadata Storage Server with Sun Fire
X4270 M2 Servers
The environmental requirements for Oracle Exadata Storage Expansion Rack with
Exadata Storage Server with Sun Fire X4270 M2 Servers depend on the size of the
system.
each type of Oracle Exadata Storage Expansion Rack with Exadata Storage Server
with Sun Fire X4270 M2 Servers.
Table 1-14
Rack with Exadata Storage Server with Sun Fire X4270 M2 Servers
Environmental
Component
Weight
Acoustic levels
Power
Cooling
(Cont.) Environmental Requirements for Oracle Exadata Storage
Oracle Exadata
Storage Expansion
X3-2 Full Rack
42 for Ethernet
network, assuming
single cluster
18 for InfiniBand
network
Minimum of 1 network
drop
12 InfiniBand ports
Table 1-14 (page 1-25) shows the general environmental requirements for
Environmental Requirements for Oracle Exadata Storage Expansion
Oracle Exadata
Storage Expansion
Full Rack
917.6 kg (2023 lbs)
83 db(A)
Maximum: 12.6 kW
(12.9 kVA)
Typical: 8.8 kW (9.0
kVA) (varies based on
application load)
Maximum: 43,000
BTU/hour (45,400 kJ/
hour)
Typical: 30,100 BTU/
hour (31,800 kJ/hour)
General Environmental Requirements
Oracle Exadata Oracle Exadata
Storage Expansion Storage Expansion
X3-2 Half Rack X3-2 Quarter Rack
24 for Ethernet 13 for Ethernet
network, assuming network, assuming
single cluster single cluster
9 for InfiniBand 4 for InfiniBand
network network
Minimum of 1 network Minimum of 1 network
drop drop
12 InfiniBand ports 12 InfiniBand ports
Oracle Exadata Oracle Exadata
Storage Expansion Storage Expansion
Half Rack Quarter Rack
578.3 kg (1275 lbs) 396.8 kg (875 lbs)
82 db(A) 81 db(A)
Maximum: 6.9 kW Maximum: 3.4 kW
(7.1 kVA) (3.5 kVA)
Typical: 4.8 kW (5.0 Typical: 2.4 kW
kVA) (varies based on (2.5kVA) (varies
application load) based on application
load)
Maximum: 23,600 Maximum: 11,600
BTU/hour (24,900 kJ/ BTU/hour (12,250 kJ/
hour) hour)
Typical: 16,500 BTU/ Typical: 8,100 BTU/
hour (17,400 kJ/hour) hour (8,600 kJ/hour)
