Tieline Merlin PLUS User Manual page 91

Launching the HTML5 Toolbox Web-GUI
1. Click to launch the HTML5 Toolbox Web-GUI.
2. When you launch Toolbox for the first time an authentication dialog prompts you to enter the
user name "admin" and password "password" to login, then click the OK button. Tieline highly
recommends you change the password (see
better network security to maintain reliability during live broadcasts.
Launching the HTML5 Toolbox Quick Connect
1. Click to launch the HTML5 Toolbox Quick Connect Web-GUI.
2. When you launch Toolbox for the first time an authentication dialog prompts you to enter the
user name "admin" and password "password" to login, then click the OK button. Tieline highly
recommends you change the password (see
better network security to maintain reliability during live broadcasts.
Using the Web-GUI over the Internet
If your codec is connected over the internet via a public static IP address it is possible to connect
and configure it from any PC also connected to the internet.
LAN Troubleshooting
PC LAN Settings
Check the LAN settings on your PC if it is connected to a LAN and is having trouble opening the
Toolbox Web-GUI in a web-browser.
1. Open Internet Explorer.
2. Click Tools > Internet Options > Connections.
3. Click the LAN settings button.
4. If the PC is using a proxy server over the LAN you may need to select the Bypass
© Tieline Pty. Ltd. 2017
proxy server for local addresses option box.
Merlin PLUS User Manual v2.0
Changing the Default Password). This will provide
Changing the Default Password). This will provide
91
