Tieline Merlin PLUS User Manual page 152

152 Merlin PLUS User Manual v2.0
For ISDN, settings are determined by ISDN module answering settings. For more details
see Configuring ISDN
For POTS, settings are determined by POTS module answering settings. For more
details see
3. After configuring all settings there are 3 options:
Configuring Rules
1. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
remove a rule.
Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO (LIO) in a
Tieline WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and
Merlin PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
·
Tieline WheatNet-IP codecs require Wheatstone Razor firmware version 1.4.22 or later
to support WheatNet LIOs. In addition, the WheatNet-IP codec must have the WNet
Enable LIO checkbox enabled in the Options panel of the HTML5 Toolbox Web-GUI.
·
Connection-related rules are not displayed in Answer only programs.
2. Click Save Program to save the program.
3. Click Finish to exit the wizard.
Answering.
Configuring POTS Answering.
i. If you want to create another answering connection, select the check-box for
Create another answering connection and continue through the wizard.
ii. Click Save Program to save the program at this point.
iii. Click Next to configure rules options.
Creating Rules
to add a new rule and click the Minus symbol
for more information.
to
© Tieline Pty. Ltd. 2017
