The explanations within the following table can be used to assist with failover connection
configuration.
Screen Display
1 Threshold
2 Time Frame
3 Keep Alive
4 Failback Parameters
5 Stable Time
6 Maximum Retries
7 Time Frame
2. Enter a name for the backup connection.
3. After configuring all settings there are 2 options:
4. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
to remove a rule.
Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO in a Tieline
WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and Merlin
PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
Description
The percentage of lost data measured during a given time
frame
The time frame against which lost data is measured
The keep connection alive time before failing over to a
backup connection; Tieline RTP pings every second to
confirm connectivity
Select the check-box to fail back to a higher priority
connection
The amount of time a primary connection must remain
stable before attempting to fail back from the backup
connection
The maximum number of fail back retries a codec can try
before ending fail back attempts
The time frame used to measure the number of fail back
retries attempted
i. Click Next to configure rules options.
ii. Click Next Stream to configure the second audio stream.
Creating Rules
to add a new rule and click the Minus symbol
for more information.
