Configure 2 Mono Peer-to-Peer Answering Programs in Merlin

23.9
It is possible to create two simultaneous mono peer-to-peer audio stream connections with different
codecs. This is similar to a 'Dual Mono' profile in G3 Tieline codecs.
The following program wizard procedure displays the configuration screens to create an answering
connection for each incoming call. See
about individual settings within the program wizard.
Routing 2 Incoming Mono Audio Streams to Specific Codec Outputs
Important Notes: Before you start program configuration please note:
If your intention is to ensure 2 incoming mono peer-to-peer audio stream connections are always
routed to the same outputs, configure a new answering program as follows:
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select
Program Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
·
Click in the text box to name the new program.
·
Select 2 x Mono Peer-to-Peer, or if you want to use an existing program as a
template, select this option. Then click Next.
3. Enter a name for the Audio Stream, add a caller ID and configure the codec to Answer
only. Then click Next. Note: The caller ID is used to identify calls. If the codec you are
configuring needs to dial connections as well as answer, you can select Dial or answer
·
You cannot edit a program when it is currently loaded in the codec.
·
You can lock a loaded custom program
program cannot be unloaded by a codec dialing in with a different type of program.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available and the transport selected (e.g. IP or ISDN).
·
It is possible to save a program at several points throughout the program wizard and
use default settings to save configuration time.
·
Failover and SmartStream PLUS redundant streaming are not available with SIP or
sessionless IP connections.
·
To learn more about programs see the section titled
Configuring Merlin Point-to-Point Programs
in a codec to ensure the currently loaded
for more details
About Program Dialing.
