17 Multiple Stream Programs
Programs can be configured to connect a single audio stream to multiple destinations, or connect
multiple audio streams to different destinations.
2 x Mono Peer-to-Peer Programs
A 2 x Mono Peer-to-Peer program includes two mono audio streams. Each audio stream includes
a separate peer-to-peer connection to a different destination, which can also be configured with
different transport, audio and backup settings.
18 6 x Mono Programs
A 6 x Mono Peer-to-Peer program includes six bidirectional mono audio streams. Each audio
stream is a separate peer-to-peer connection with a different remote codec or smartphone using the
Report-IT codec application. Each connection can also be configured with unique settings.
© Tieline Pty. Ltd. 2017
Peer-to-peer connection configured via the codec front panel
Merlin PLUS User Manual v2.0 61
