10 Merlin PLUS Headphone/Aux Output
The codec has a 6.35mm (1/4") RTS stereo HEADPHONE output for monitoring inputs and return
audio. If you are using analog inputs or digital inputs you will see audio metering on the PPMs and
can monitor it with the headphones.
Important Note: The front panel HEADPHONE output and rear panel HP/AUX output
share the same hardware output. This means both are switched and configured together.
I.e. both outputs are either a stereo headphone output (default setting), or a balanced
mono auxiliary output.
Configure for Headphone and Aux Output
Both the front panel HEADPHONE and rear panel HP/AUX outputs are configured as stereo
headphone outputs by default. To adjust this setting:
1. Press the SETTINGS
2. Navigate to Audio and press
3. Select HP/Aux Out and press
Adjust Headphone Output Settings
1. Press the HEADPHONE
2. Use the left
displays level adjustments in real-time.
3. Press the down
or right
whether the front panel HEADPHONE output and the rear panel HP/AUX output monitors send
(input/encoder) audio only, return audio only (decoder audio from a connected device), or a mix
of both send and return audio.
4. Press RETURN
Note: Headphone levels can also be adjusted by pressing the SETTINGS
Audio and then HP Vol/Bal and press
Adjusting the Monitor Source
In headphone listen mode it is possible to select monitoring sources via HEADPHONE
Monitor Source > [Select audio Source].
© Tieline Pty. Ltd. 2017
button.
button to display the headphone monitoring adjustment screen.
or right navigation buttons to adjust the volume level up or down. The screen
navigation button to select the Send/Return audio balance and use the left
navigation buttons to adjust the balance. The Send/Return audio balance dictates
when you have finished to exit the menu.
Merlin PLUS User Manual v2.0
.
to toggle between Headphone and Aux Out.
.
35
button, navigate to
>
