90 Merlin PLUS User Manual v2.0
22 Connecting to the ToolBox Web-GUI
There are two graphical user interface (GUI) options for configuring and connecting Tieline G5
codecs:
1. HTML5 Toolbox Web-GUI: fully configure codec settings, create dialing programs and dial,
hangup and monitor connections.
2. HTML5 Toolbox Quick Connect Web-GUI: designed for dialing and managing simple peer-to-
peer connections; ideal for non-technical users.
About the HTML5 Toolbox Web-GUI
The HTML5 Toolbox Web-GUI improves the user experience with G5 codec command and control
and runs seamlessly on modern browsers. The HTML5 Toolbox Web-GUI will run on Mac, Windows
and Linux computers.
About the HTML5 Toolbox Quick Connect
The HTML5 Toolbox Quick Connect Web-GUI has a reduced feature-set and allows non-technical
users to load existing programs and dial via the Quick Connect panel. Users can dial a simple
peer-to-peer connection over POTS, ISDN or IP. To enable the Quick Connect panel press the
SETTINGS
22.1 Opening the HTML5 Web-GUI & Login
1. Attach an Ethernet cable to the ETH1 port on the codec.
2. Press the SETTINGS
your codec.
3. Ensure your PC is connected to the same LAN.
4. Open your web browser and type the IP address of your codec into the address bar of your
browser, e.g. http://192.168.0.xxx (the last digits are the private address details unique to your
codec over a private LAN).
5. Refresh the browser and the Web-GUI landing page will display the various command and control
options.
button, then navigate to WebGUI > Quick Connect > Enabled.
button and select Unit to display the IP address programmed into
