Tieline Merlin PLUS User Manual page 160

160 Merlin PLUS User Manual v2.0
·
POTS is not supported for stereo audio stream connections.
·
To learn more about programs see the section titled
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the Create New Program button to open the wizard and:
·
Click in the text box to name the new program.
·
Select Mono/Stereo Peer-to-Peer + IFB, or if you want to use an existing program as a
template, select this option. Then click Next. Note: The following example is configured to
connect a stereo audio stream and mono IFB stream.
Important Note: When you decide to use an existing program as a template, the new
program inherits all the settings of the template program and you can adjust these
settings as required by continuing through the program wizard.
3. Enter a name for the Audio Stream, add a caller ID and configure the codec to Dial only.
Then click Next. Note: The caller ID is used to identify calls.
Routing Type Options:
Default No Dial Route or Answer Route is configured. An incoming call will be
routed to an audio stream on a first-come, first-served basis in a multi-
stream program. Note: By default IP streams are routed using audio
ports.
About Program Dialing.
© Tieline Pty. Ltd. 2017
