218 Merlin PLUS User Manual v2.0
12. Click Next to configure the jitter and FEC settings for the answering connection.
13. After configuring all settings there are 3 options:
i. If you want to create another answering connection, select the check-box for Create
another answering connection and continue through the wizard.
ii. Click Next Stream to configure the next audio stream.
iii. Click Next to configure rules options.
14. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
to remove a rule.
Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO in a Tieline
WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and Merlin
PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
·
Connection-related rules are not displayed in Answer only programs.
·
Relay reflection is not available for SIP and Multicast Client programs.
Configure the Second Peer-to-Peer SIP Audio Stream
1. Click Next Stream to name the second Audio Stream and configure the codec to dial, answer
or dial and answer. Then click Next.
to add a new rule and click the Minus symbol
Creating Rules for more information.
