15. The newly created program will be displayed in the left pane within the Program Manager
panel and in the Program Loader panel.
23.14

Configure 6 x Mono Peer-to-Peer Answering Programs

A Genie Distribution codec at the studio can accept six simultaneous bidirectional mono peer-to-
peer audio stream connections from different remote codecs. The following image displays the
default audio port settings used when creating a 6 x Mono Peer-to-Peer answering program.
Remote codecs configured with corresponding audio port settings will route audio to specific
inputs/outputs of the codec as shown.
Both mono and stereo audio stream connections can be answered by the Genie Distribution codec
when using a 6 x Mono Peer-to-Peer program. To do this load and lock a 6 x Mono Peer-to-
Peer answering program in the codec at the studio. If a codec using a stereo program attempts to
connect then the studio codec will accept the call and mix the two incoming audio channels into a
single audio channel to allow a mono peer-to-peer connection.
Routing 6 Incoming Mono Audio Streams to Specific Codec Outputs
Important Notes: Before you start program configuration please note:
© Tieline Pty. Ltd. 2017
to 6 are 9020, 9030, 9040 and 9050. If you need to change this setting on your dialing
codec, or in your Report-IT smart phone application, this will need to be adjusted
accordingly in the answering codec.
·
You cannot edit a program when it is currently loaded in the codec.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available and the transport selected (e.g. IP or ISDN).
·
It is possible to save a program at several points throughout the program wizard and
use default settings to save configuration time.
·
You can lock a loaded custom program
program cannot be unloaded by a codec dialing in with a different program type.
·
To learn more about programs see the section titled
·
6 audio streams must be configured.
·
Failover and SmartStream PLUS redundant streaming are not available with SIP or
sessionless IP connections.
Merlin PLUS User Manual v2.0
in a codec to ensure the currently loaded
About Program
191
Dialing.
