Configure Tieline G3 Codec Audio Reference Scales
Genie, Merlin, Bridge-IT and ViA codecs have more audio headroom than Tieline G3 audio codecs,
therefore the audio metering reference scale needs to be adjusted when these codecs connect to a
Commander or i-Mix G3 codec. The G3 metering scale is between -29dBFS and 0dBFS and audio
levels should average around the nominal 0vu point at -14dBFS. Audio peaks should not exceed
0dBFS.
1. Press the SETTINGS
2. Navigate to Audio and press
3. Navigate to Ref Level and press
4. Select Tieline G3 and press
Important Note: If your codec (Genie STL, Genie Distribution and Bridge-IT) supports
sending multi-unicast connections and the Auto (default) reference level is selected, the
first codec to which you connect configures the reference level used for all subsequent
multi-unicast connections.
© Tieline Pty. Ltd. 2017
Merlin PLUS User Manual v2.0
button.
.
.
.
