Tieline Merlin PLUS User Manual page 105

Transport Panels
There are several Transport panels which can be opened in
the Web-GUI. Each panel provides specific transport-related
configuration settings and options. Click to select and open
each panel.
As an example, the Network panel is displayed with network interface configuration options. A
brief description of the other panels is also provided.
Feature
1 Network interfaces
2 Details tab
3 Control/Streaming
4 TCP/IP and DNS tabs
5 Enable check-box
6 Save/Undo button
7 Fuse-IP
8 IP Via Mapping
9 ISDN Answer
10 Modules
11 Network
12 POTS Answer
© Tieline Pty. Ltd. 2017
Description
Click to select and edit, or view network configuration settings for
each Ethernet and VLAN interface.
Display configuration options for a selected network interface, plus
other device details.
Select Control and/or Streaming options for the selected interface.
Select the TCP/IP tab to configure IPv4/IPv6 address details.
Select the DNS tab to specify DNS addresses and domains to
search.
Select the check-box to enable an interface.
Click Save to store settings, or click Undo to revert to previously
configured settings.
Click to open the Fuse-IP panel and configure Fuse-IP bonding
Configure default Primary, Secondary and Tertiary interfaces.
Click to open the panel and configure ISDN Answering settings.
Click to edit hardware module configuration.
Click to open the Network panel and configure network settings.
Click to open the panel and configure POTS Answering settings.
Merlin PLUS User Manual v2.0 105
