196 Merlin PLUS User Manual v2.0
ii. Click Next Stream to configure the next audio stream.
6. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
to remove a rule.
Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO in a Tieline
WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and Merlin
PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
·
Connection-related rules are not displayed in Answer only programs.
7. Click Next to configure the second audio stream.
Configure the Second Peer-to-Peer Audio Stream
1. Enter a name for the second Audio Stream, add a caller ID and configure the codec to
Answer only. Then click Next.
2. Enter the name of the audio stream connection in the text box and click Next.
to add a new rule and click the Minus symbol
Creating Rules for more information.
