172 Merlin PLUS User Manual v2.0
will avoid the first mono or stereo call unloading the Peer-to-Peer + IFB program at the
studio and loading a mono or stereo peer-to-peer program, which would cause the second
connection to fail.
Configuring Mono or Stereo Peer-to-Peer + IFB Programs
In most situations the studio codec will answer incoming audio stream connections from the remote
site. The following procedure outlines configuration of an answering program for the studio codec.
Important Notes: Before you commence program configuration please note:
·
The auxiliary input is used by default for the IFB communications channel in Merlin
codecs. In Merlin PLUS codecs the auxiliary input and XLR input 3 are mixed
together by default for 1 x Mono/Stereo + IFB programs.
·
You cannot edit a program when it is currently loaded in the codec.
·
You can
program cannot be unloaded by a codec dialing in with a different type of program.
·
If the codec at the studio will receive both mono and stereo peer-to-peer + IFB calls
from different remote sites at different times, we recommend you configure and load a 1
x Stereo Peer-to-Peer + IFB answering program and
studio. This will accept both mono and stereo audio stream connections. If a codec
with a Mono Peer-to-Peer + IFB program calls the studio, the incoming mono stream
will be mixed to both the left and right outputs at the studio.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available and the transport selected (e.g. IP or ISDN).
·
It is possible to save a program at several points throughout the program wizard and
use default settings to save configuration time.
·
Failover and SmartStream PLUS redundant streaming are not available with SIP or
sessionless IP connections.
·
POTS is not supported for stereo audio stream connections.
·
To learn more about programs see the section titled
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
·
Click in the text box to name the new program.
·
Select Mono/Stereo Peer-to-Peer + IFB, or if you want to use an existing program as a
template, select this option. Then click Next.
Important Notes: When you decide to use an existing program as a template, the new
program inherits all the settings of the template program and you can adjust these
settings as required by continuing through the program wizard.
3. Enter a name for the Audio Stream, add a caller ID and configure the codec to Answer only.
Then click Next. Note: The caller ID is used to identify calls. If the codec you are configuring
needs to dial connections as well as answer, you can select Dial or answer and configure both
lock a loaded custom program in a codec to ensure the currently loaded
lock this in the codec
About Program
at the
Dialing.
