Auxiliary Input Adjustment
The codec has 1 x 6.35mm (1/4") Mic/Line level Jack on the rear panel. By default the input is Off
and can be configured by:
1. Selecting the SETTINGS
2. Navigate to Audio and press the
3. Use the arrow-down
options.
Input settings which can be adjusted include:
·
Input on/off.
·
Input level.
·
Input Type: High Gain Mic, Medium Gain Mic, Low Gain Mic, Unbalanced and Line Level.
·
Phantom power (15V available when enabled).
·
IGC.
Important Note: When the auxiliary input (AUX IN) is On the default mixer configuration
sends audio to all inputs. If you are not using the auxiliary input ensure it is Off to avoid
additional noise in program audio.
Ganging Audio Channels
It is possible to gang channels together and adjust the audio level of the ganged channels
simultaneously. When channels are ganged together:
·
Both channels highlight together when selected.
·
The gain setting for both channels is automatically set to match the gain level of the lowest of
the two channels when ganging is first configured.
·
If one channel is turned on when ganging is first configured then the other one will be turned
on automatically.
1. Press the SETTINGS
2. Navigate to Audio and press
3. Use the down
4. Navigate to the channels you want to gang and press the
5. Navigate to the Gang function and press the
6. Use the up
7. Use the left
8. Press the RETURN
Important Note: To gang channels quickly press
arrow button to open the Input Audio Level adjustment screen and follow the preceding
© Tieline Pty. Ltd. 2017
button to select Aux Input and press the
navigation button to highlight Input Level and press the
Disabled.
and down
and right
simultaneously.
Merlin PLUS User Manual v2.0
button.
button.
button.
.
arrow buttons to highlight and select the audio channels.
arrow buttons to adjust the levels for both inputs up or down
or HOME buttons to exit the screen.
button to view menu
button.
button to toggle between Enabled or
and press and release the right
31
button.
