Tieline Merlin PLUS User Manual page 145

Important Note: The G3 profile setting supports maintaining specific G3 codec settings
when answering a call from a G5 codec.
4. This audio stream connection in the wizard will allow the codec to dial. Enter the name of the
connection in the text box, then click Next.
5. Follow the instructions on the right-hand side of the panel to configure the transport settings for
the connection, then click Next.
Important Note:
·
If you select Sessionless as the Session Protocol select UDP/IP +RTP for RFC-
compliant IP streaming.
·
See
Relays and RS232 Data
6. Configure destination codec dialing and encoding settings:
© Tieline Pty. Ltd. 2017
1. Auto: The codec will dial the G3 codec and connect in mono or stereo. Note: This
is overridden in a Merlin or Merlin PLUS codec when a G3 Main + IFB use-case is
configured.
2. Dual Program: This allows the codec to dial a G3 codec with a Dual Program
profile loaded and support two simultaneous mono connections.
3. Runtime: The G3 codec will retain runtime settings when answering a call from a
G5 codec.
4. Custom: The G3 codec will load a specified profile, e.g. profile 6, which is the first
custom profile number.
RS232 Data Configuration
Merlin PLUS User Manual v2.0
for detailed information on RS232 data and see
for more information on relay operations.
145
Enabling
