Tieline Merlin PLUS User Manual page 156

156 Merlin PLUS User Manual v2.0
5. Configure the transport settings:
For IP click the drop-down Session Protocol menu and select Tieline Codecs and
ensure the Any check-box is not selected, then click Next to specify individual algorithm,
jitter buffer and FEC settings, or create another answering connection.
Click to configure:
·
·
·
ISDN module answering settings are used if you select ISDN as the connection transport.
For more details see Configuring ISDN Answering.
Important Note: The Local Audio Port is used by the local codec to receive
audio from the remote codec. When Tieline Codecs is the Session Protocol
selected (using Tieline session data), the Local Audio Port is automatically
configured as UDP audio port 9000 by default for the first audio stream
connection. Deselect the Any check-box to adjust this setting. A codec dialing
this connection and using the port specified will always be routed to output 1
on the codec receiving the call.
Auto Jitter Adapt and the preferred auto jitter setting using the drop-down arrow for
Buffer priority. It is also possible to configure the Minimum depth and Maximum
depth of jitter over the connection. See
Alternatively, select a Fixed Buffer Level and enter the Jitter Depth, which must
be between 12ms and 5000ms depending on the algorithm you select.
Local FEC settings if required.
Configuring the Jitter Buffer for more details.
