142 Merlin PLUS User Manual v2.0
3. Click Save to store the new setting.
Renaming Inputs
1. Select the Input Settings
2. Click in the Name text box to enter a new name, or edit an existing name.
3. Click Save to confirm the name change.
Important Note: When the auxiliary input (AUX IN) is On the default mixer configuration
sends audio to all inputs. If you are not using the auxiliary input ensure it is Off to avoid
additional noise in program audio.
AES3 Output Sample Rate Configuration
The AES3 output sample rate can be configured using the HTML5 Toolbox Web-GUI.
1. Open the HTML5 Toolbox Web-GUI and click Settings
the Options panel.
2.
Click the AES Output Clock drop-down menu to select your preferred AES Output Clock
setting, then click Save.
symbol on the input being renamed.
then click Options to open
,
