If you want to dial a codec with a public IP address you simply dial the IP address to connect. If you
want to dial a codec with a private IP address you need to perform network address translation
(NAT). NAT allows a single device, such as a broadband router, to act as an agent between the
public internet and a local private LAN. Usually this will be set up at the studio end so you can dial
into the studio from the remote codec.
Support for IPv6 connections allows you to use IPv6 infrastructure to connect to other codecs
globally.
Configuring Ethernet Ports and VLANs
The codec features two physical Ethernet port interfaces and up to four additional VLAN interfaces.
VLAN interfaces have features similar to physical Ethernet interfaces. However, your network
administrator will need to configure VLAN support throughout your network for them to be supported
in your codec.
As an example, if only one physical Ethernet interface is available, VLANs can be used to operate
SmartStream PLUS or to separate codec Control and Streaming functions if required. Ethernet
and VLAN interfaces can be configured for:
·
Controlling audio: codec control and command only from the Ethernet port.
·
Controlling and Streaming: stream audio and control and command the codec via the Ethernet
port.
·
Streaming audio: stream audio only from an Ethernet port (ETH2 and VLANs only).
·
Nothing: Disable the Ethernet port from streaming audio and codec command and control
(VLANs only).
The Name text box, e.g. Primary or Secondary, is an interface identifier used when configuring
new programs via the Programs panel.
IPv4 Address Configuration
Click the Edit button in the Network panel to configure settings. The codec is capable of automatic
DHCP address assignment, or manually configured static IPv4 address configuration via the drop-
down Configure IPv4 menu. If you want to ignore IPv4 settings select Off.
© Tieline Pty. Ltd. 2017
Merlin PLUS User Manual v2.0
117
