For IP connections configure the IP address, ports, and then specify which streaming
interface is used to dial this connection, e.g. Primary (port ETH1) or Secondary (port
ETH2). Note: By default Any will select ETH1 if it is available and ETH2 if it is unavailable.
Important Note: The Remote Audio Port is the codec port at the remote end of
the link to which you are sending audio. The Local Audio Port is used by the
local codec to receive audio from the remote codec. When Tieline Codecs is the
Session Protocol selected (using Tieline session data), the default port value for
the Local Audio Port is Automatic. Note: Automatic indicates that the codec
will arbitrarily allocate the local port value and send this information to the codec to
which you are dialing. Click to deselect the Automatic check-box and change this
setting. When you select Sessionless as the Session Protocol, the Session
Port is not configurable and you can manually configure the Remote Audio Port
and Local Audio Port.
Click Save Program to save the program with the default algorithm, jitter and FEC settings
which are physically entered in the codec. Alternatively, click Next to specify individual
algorithm, jitter buffer and FEC settings and configure a failover connection or SmartStream
PLUS for this audio stream (recommended).
Click the drop-down arrows on the right-hand side of each text box to adjust the Encoding
Sample rate and Bit rate options.
For IP connections click to configure:
·
Auto Jitter Adapt and the preferred auto jitter setting using the drop-down arrow for
Buffer priority. It is also possible to configure the Minimum depth and Maximum
depth of jitter over the connection. See
·
Alternatively, select a Fixed Buffer Level and enter the Jitter Depth, which must be
between 12ms and 5000ms depending on the algorithm you select.
·
Local and Remote FEC settings if required.
Configuring the Jitter Buffer
,
for more details.
