Tieline Pty. Ltd - Tieline Merlin PLUS User Manual

and configure both dialing and answering connections. For the purposes of this example
dialing is excluded.
Routing Type Options:
Default
Deterministic
Line Hunt
Important Note: The G3 profile setting supports maintaining specific G3 codec settings
when answering a call from a G5 codec.
4. Enter the name of the connection in the text box, then click Next.
© Tieline Pty. Ltd. 2017
No Dial Route or Answer Route is configured. An incoming call will be
routed to an audio stream on a first-come, first-served basis in a multi-
stream program. Note: By default IP streams are routed using audio
ports.
Select a Dial Route or Answer Route to configure deterministic routing
of multiple audio streams using transports like ISDN or POTS. Use of
Dial and Answer Routes is not necessary over IP. See
Answering
Create line hunt groups for multiple incoming callers on a first come, first
served basis. This is ideal for separating groups of inputs and outputs
between different studios or stations. See
more information.
1. Auto: The codec will dial the G3 codec and connect in mono or stereo. This is
overridden in a Merlin or Merlin PLUS codec when a G3 Main + IFB use-case is
configured.
2. Dual Program: This allows the codec to dial a G3 codec with a Dual Program
profile loaded and support two simultaneous mono connections.
3. Runtime: The G3 codec will retain runtime settings when answering a call from a
G5 codec.
4. Custom: The G3 codec will load a specified profile, e.g. profile 6, which is the first
custom profile number.
Merlin PLUS User Manual v2.0
or Configuring POTS Answering
Configuring ISDN
for more information.
Line Hunt Call Answering
155
for
