Tieline Merlin PLUS User Manual page 175

POTS settings are determined by POTS module answering settings. For more details
see
6. After configuring all settings there are 3 options:
7. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
remove a rule.
Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO in a Tieline
WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and Merlin
PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
·
Connection-related rules are not displayed in Answer only programs.
8. Click Next to configure the IFB audio stream. Enter the IFB Audio Stream name, add a caller
ID and configure the codec to Answer only. Then click Next.
9. Enter the IFB audio stream connection name in the text box and click Next
© Tieline Pty. Ltd. 2017
Configuring POTS Answering.
i. If you want to create another answering connection, select the check-box for
Create another answering connection and continue through the wizard.
ii. Click Next to configure rules options.
iii. Click Next Stream to configure the IFB audio stream.
Creating Rules
Merlin PLUS User Manual v2.0
to add a new rule and click the Minus symbol
for more information.
175
to
.
