Install data cartridges in the magazines
1. Place the magazine on its feet with the single mounting guide
2. Position each cartridge so that the bar code label is on top and
3. Insert the cartridge into the magazine slot.
Write-protect
switch
Note: Very little force is needed to install a data cartridge. If it
Installation and Operation
on the right.
the write-protect switch is closest to you, as shown in the
following figure.
does not snap into place easily, check the orientation of
the cartridge.
Installation and Setup
Mounting
guide
