Chapter 11
The following table describes the information in the System
Sensors screen.
190
Field name Description
Front Door 0 – The library door is closed.
Open
1 – The library door is open.
Key Lock 0 – The library door is unlocked.
1 – The library door is locked.
Cartridge 0 – No cartridge is seated in the robot.
Seated
1 – A cartridge is seated in the robot.
Drum Index 0 – The drum is located 180° from its home position.
1 – The drum is not located 180° from its home
Grip Home 0 – The gripper is not in the home position; grip
1 – The gripper is in the home position; grip fingers
EE Port 0 – The entry/exit port is not extended.
Extended
1 – The entry/exit port is extended.
EE Port 0 – The entry/exit port is not retracted.
Retracted
1 – The entry/exit port is retracted.
EE Port 0 – The entry/exit port door is closed.
Door Open
1 – The entry/exit port door is open.
Top P/S 0 – The top library power supply is operational.
Fail
1 – The top library power supply has failed.
Bottom P/S 0 – The bottom library power supply is operational.
Fail
1 – The bottom library power supply has failed.
Power Dist. 0 – The fan for the power supply is operational.
Fan Fail
1 – The fan for the power supply has failed.
Digital System Sensors
position.
fingers are closed.
are open.
