Step 3 – Attach reflective plates to the mounting
plates
Re-attach the reflective plates to the new mounting plates by
following these steps for each plate:
1. Position the reflective plate in front of the mounting plate, as
Reflective
plate
2. Insert the bottom end of the reflective plate first so that the tab
132
shown in the figure.
Mounting
plate
Release tab
Tab
is positioned in the mounting plate slot, then snap the plate
into place by pressing against the top.
