2. Place the mounting plate against the drum spindle, and line
3. Using a T-20 TORX bit, attach the two 8-32
4. Attach the next mounting plate at the same horizontal level
5. Repeat steps 1 to 4 for the remaining mounting plates.
Installation and Operation
up the screw holes on the plate with the screw holes on the
drum.
Screws
screws to secure the magazine mounting plate to the drum.
Tighten the screws to 15.0 inch-pounds (17.2 kg-cm) of torque.
on the drum spindle.
Library Upgrades
×
0.5 panhead
