Figure 45
88
SAN32M-2 Installation and Service Manual
For the EFCM application, critical configuration data is stored on the
management server hard drive in the following directories:
•
C:\Program Files\EFCM 8.7\CallHome
•
C:\Program Files\EFCM 8.7\Client
•
C:\Program Files\EFCM 8.7\Server.
The server is configured to automatically mirror the contents of these
directories to the CD-RW drive anytime directory contents change or
the server is rebooted. The directories contain all SAN management
configuration data, log files, firmware versions, call-home and other
configuration data; and are used to restore the server operating
environment in case of hard drive failure.
The server does not back up Windows operating system data, such as
user names, passwords, date and time, and network information.
This information was recorded while performing installation tasks,
and verified while performing
information.
To back up server configuration data and create a base restore CD:
1. Insert a blank rewritable CD into the CD-RW drive and format
the CD:
a. At the Windows desktop, locate the InCD icon (1) at the right
side of the task bar
down arrow.
InCD icon (unformatted CD)
b. Right-click the icon and select Format (F). The first window of
the InCD wizard displays.
c. Click Next to proceed to the second window of the InCD
wizard. Use default parameters displayed at each window,
and click Next and Finish as appropriate to complete the CD
formatting task.
Task 13: Record or verify server restore
(Figure
45). The icon is indicated by a red
1
