8. Print Unit

8.1 Description

Ribbon Rewind Unit
Print Unit
Liner/Batch Takeup Unit
Ribbon Rewind Unit
Print Unit
Intermec EasyCoder 501 XP & 601 XP – Service Manual
The print unit is partly integrated with the ribbon rewind unit (see
Chapter 7.3) and optional liner/batch takeup unit (see Chapter 9).
(option)
Liner Takeup Unit
(option)
EasyCoder 501 XP
EasyCoder 601 XP
Chapter 8
47
