Chapter 16
16. Interfaces

16.1 Introduction

132
The EasyCoder 501 XP and 601 XP are fi tted with a number of
interfaces:
• Operator interface consisting of the display, the keyboard, and
the beeper, see Chapter 2.
• Cutter Interface for connection of an optional paper cutter, see
Chapter 11.
• Bar Code Wand interface for connection of an EasySet bar code
wand, see Chapter 15.4.
• Memory Card interface for connection of a memory card, see
Chapter 15.4.
• RS-232 Serial Communication interface ("uart1:") for commu-
nication with the host computer, or for connection of a bar code
reader, an external keyboard etc., see Chapter 16.2.
• Parallel Communication interface ("centronics:") for parallel
one-way communication with the host computer, see Chapter
16.3.
• Optional interface boards, see Chapters 16.4-16.8.
The rest of this Chapter will only deal with the three last para-
graphs.
By default, "uart1:" is the standard IN and OUT communication
port. To select another communication port as standard IN and/or
standard OUT port, use an Intermec Fingerprint SETSTDIO state-
ment (see Intermec Fingerprint v7.61, Programmer's Reference
Manual.) Note that many application programs, for example Inter-
mec Shell, contains instructions that select the correct std I/O for
the application in question.
