8.6 Label Stop Sensor,
cont.
Upper part of LSS
Detection Slot
Intermec EasyCoder 501 XP & 601 XP – Service Manual
Adjustment of the Lateral Position (EasyCoder 501 XP and 601
XP), cont.
Upper part of print unit omitted to improve view.
Chapter 8 Print Unit
EasyCoder 601 XP.
Linear Markings
Adjustment
Screw
65
