1.4 EasyCoder 501 XP Measures

68.8 mm
An optional paper cutter increases the printer's total length by 28 mm (1.1 inches).
At least 90 mm (3.5 inches) of free space behind the printer is required for the connectors,
Intermec EasyCoder 501 XP & 601 XP– Service Manual
37 mm
(1.46")
135.4 mm (5.33")
(2.71")
and for inserting and removing a memory card.
201 mm (7.91")
120 mm (4.72")
275 mm (10.83")
Dot No. 0
363 mm (14.29")
481.5 mm (18.96")
Chapter 1 Models and Options
238 mm
(9.37")
79 mm
(3.11")
Paper slot
Paper slot
20 mm
(0.79")
186 mm
(7.32")
20 mm
(0.79")
30 mm
(1.18")
12 mm
(0.47")
17
