Why does the printhead
wear out?
Simple precautions
EasyCoder 501 XP
Thermal Printhead
Installation Instructions
Edition 2, September 1998
Part No. 1-960448-01
Intermec EasyCoder 501 XP Thermal Printhead– Installation Instructions Ed. 2
The EasyCoder 501 XP is fitted with a 12 dots/mm high-perform-
ance thermal printhead. While the receiving face material (e.g.
labels, tickets, or continuous strip) is fed past the printhead, small
resistor elements (dots) on the printhead are electrically charged
and thereby heated. The heat from the dots is transferred to the
thermal transfer ribbon or direct thermal paper so as to form the dot
pattern which makes up the text, images or bar codes.
Printhead wear-out is an inevitable process which applies to all
thermal printers regardless of brand. During printing, the dots must
be heated and cooled off very rapidly, which in combination with
mechanical abrasion sooner or later will wear out the printhead,
making the printout gradually weaker. Some dots may even cease
to produce any imprint.
Some measures can be taken to prevent premature wear-out:
• Clean the printhead regularly, as described in the Installation &
Operation manual. Not only will a dirty printhead produce an
inferior printout, but any residue on the dots will prevent heat to
dissipate through the transfer ribbon and paper.
• Use original Intermec transfer ribbons only. These are optimized
specifically for your printer. Inferior back coating on a non-
approved transfer ribbon may cause residue which can com-
pletely destroy the printhead.
• Follow the recommendations regarding Paper Type setup in the
Installation & Operation manual. Too much energy to the print-
head will wear it out rapidly.
• Do not use higher Print Speed setting than necessary.
• Do not use a higher Contrast setting than necessary, especially
not in combination with the highest Paper Type Constant
settings.
• Do not use a higher printhead pressure than necessary.
• Never print outside the paper width. Dots not in contact with the
paper will not be cooled properly.
• In case of thermal transfer printing, use a ribbon wider than the
paper (if available).
• When using a paper with less than full width, be careful to adjust
the printhead lift arm so there is an even pressure across the paper
web. Not only will an uneven pressure impair the printout
quality, but it may also prevent the dots from being properly
cooled. Moreover, a sharp outer paper edge in direct contact with
the printhead may cause excessive mechanical wear on some
dots, which may be visible when printing on wider paper later.
• When using preprinted labels or labels with some type of varnish
or non-standard top coating for direct thermal printing, use
original Intermec labels or inks recommended by leading manu-
facturer's of direct thermal paper. The labels should not contain
any aggressive substances such as chloride or grinding sub-
stances such as titanium dioxide.
Printhead Replacement
