Chapter 9 Liner/Batch Takeup Kit
9.2 Main Parts, cont.
Belt to
Liner Drive Roller
Tension Roller
92
EasyCoder 601 XP
Stepper Motor
Motor Support Plate
Belt to Liner Takeup Unit
Liner Takeup Unit
Break Shaft
Intermec EasyCoder 501 XP & 601 XP– Service Manual
Brace
