4. Chassis
4.1 Description
Center Section
Rubber Foot (x4)
Center Section
Rubber Foot (x4)
Intermec EasyCoder 501 XP & 601 XP – Service Manual
The printer's chassis is made up by three main parts:
• The center section
• The bottom plate
• The rear plate
EasyCoder 501 XP
EasyCoder 601 XP
Chapter 4
Rear Plate
Bottom Plate
Rear Plate
Bottom Plate
