Intermec EasyCoder 501 XP Service Manual page 56

Chapter 8 Print Unit
8.2 Platen Roller, cont.
Stepper Motor
#T20 Torx Screw
Belt to Platen Roller
Pulley
Ball Bearing
Plastic Bearing
54
EasyCoder 501 XP
In the illustration below, the upper parts of the print unit and the
label stop sensor have been omitted to improve visibility.
#T20 Torx Screw
Spacer
Platen Roller
Plastic Bearing
Ball Bearing
Bracket
#T20 Torx Screw (1)
Intermec EasyCoder 501 XP & 601 XP – Service Manual
Belt to Ribbon Rewind Unit
