8.10 Ribbon Assist
Roller, cont.
Ribbon Assist Roller
Locking Screw
Wrinkling
Turn Screwdriver
Inner side
counterclockwise
Outer side
clockwise
Ribbon Assist Roller
Intermec EasyCoder 501 XP & 601 XP – Service Manual
Adjustment (EasyCoder 501 XP and 601 XP), cont.
Locking Screw
#T20 Torx Screwdriver
EasyCoder 501 XP
#T20 Torx Screwdriver
EasyCoder 601 XP
Chapter 8 Print Unit
