Chapter 7
7. Transfer Ribbon Mechanism

7.1 Description

Ribbon Rewind Unit
Ribbon Rewind Unit
40
The thermal transfer ribbon mechanism is standard, but can be
omitted on special order. The mechanism consists of three main
units:
• Ribbon supply unit (see Chapter 7.2)
• Ribbon rewind unit (see Chapter 7.3)
• Ribbon-end sensor (see Chapter 7.4)
Intermec EasyCoder 501 XP & 601 XP – Service Manual
Ribbon Supply Unit
Ribbon End Sensor
Ribbon Supply Unit
Ribbon End Sensor
