Setup Mode Overview, Part 5 (FP v7.63)

If an optional an EasyLAN 100i interface board is fitted, additional menus will be displayed.
SETUP:
Standard Setup Mode
See Overview Part 1
SER-COM, UART1
SETUP:
NET-COM, NET1
Standard Setup Mode
SETUP:
See Overview Part 1
FEEDADJ
Standard Setup Mode
SETUP:
See Overview Part 2
MEDIA
SETUP:
Standard Setup Mode
PRINT DEFS
See Overview Part 2
SETUP:
NETWORK
• Press Setup key to exit the Setup Mode.
198
NET-COM,NET1:
NEW LINE
NETWORK:
IP SELECTION
NETWORK:
IP ADDRESS
NETWORK:
NETMASK
NETWORK:
DEFAULT ROUTER
NEW LINE:
CR/LF
LF
CR
IP SELECTION:
MANUAL
DHCP
BOOTP
RARP
Use keys . and 0–9 to enter netmask.
IP ADDRESS:
Use C-key to erase.
10.1.12.79
NETMASK: Use keys . and 0–9 to enter netmask.
Use C-key to erase.
255.255.0.0
Use keys . and 0–9 to enter router.
DEFAULT ROUTER:
Use C-key to erase.
10.1.12.1
