Chapter 15 CPU Board

15.4 Special Devices

120
Memory Card Adapter (P25)
The CPU board has a built-in memory card adapter which can
use special fl ash memory cards from Intermec and SRAM cards
complying with the Memory Card/JEIDA-4 standard and with a
maximum size of 64Mbit (8MB). It is not suited for other types of
memory cards!
Memory cards are only detected by the fi rmware at startup and
must thus be inserted in the memory card adapter before the power
is switched on or the printer is rebooted.
Important!
Memory cards must only be inserted or removed when the power
is off.
Flash Memory Cards
There are three types of fl ash memory cards. All such cards are
referred to as device "rom:" in Intermec Fingerprint.
• Font Cards
Must be present in the printer's memory card adapter before the
font stored in the card can be used.
• Font Install Cards
Install additional fonts in the printer's memory. These fonts can
be used without the card being present.
• Firmware Cards
Install a new fi rmware kernel in the printer incl. possible stan-
dard fonts.
JEIDA-4 PC Memory cards
There are two types:
• DOS-formatted memory cards
Such cards can be both read from and written to. In Intermec
Fingerprint they are referred to as device "card1:".
• Non DOS-formatted memory cards
Such cards are read-only and are referred to as device "rom:" in
Intermec Fingerprint.
