1.3 EasyCoder 601 XP Specifi cations
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Media Width (max/min)
Print Length (max)
Internal Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Length (max)
Ribbon Width (max)
Print Directions
Modes of Operation
Tear Off
Peel Off
Cut Off
Firmware
Operating System
Smooth Fonts
Built-in scaleable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Physical Measures
Dimensions (W x D x H)
Weight (excluding media & options)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMMs
Real-Time Clock
Power Supply
Input Voltage
PFC Regulation
Maximum Power Consumption
Intermec EasyCoder 501 XP & 601 XP– Service Manual
Direct Thermal & Thermal Transfer
12 dots/mm (304.8 dots/inch)
100 to 225 mm/sec (4 to 8.85 inches/sec)
165.3 mm (6.49 inches)
168 mm (6.61 inches)/76.2 mm (3.00 inch)
32,767 dots = 2,730 mm/107.5 inches
205 mm (8 inches)
38 to 40 mm (1.5 inches) or 76 mm (3 inches)
450 metres (1475 feet)
166 mm (6.54 inches)
4
Yes
Optional
Optional
Fingerprint v7.63 incl. Intermec Direct Protocol
TrueDoc and TrueType fonts
15
38
Intermec Shell v4.8
335 x 482 x 238 mm (13.1 x 19.0 x 9.4 inches)
15 kg (33 pounds)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
32 bit RISC
1 to 3 (2 or 4MB each)
1 to 2 (1 x 4MB + 1 x 32MB)
Yes
>90 to <264 VAC, 45 to 65 Hz
IEC 61000-3-2
Continuous 175W; Peek 400W
Chapter 1 Models and Options
1
With internal takeup unit
With cutter
Unicode fonts
Std. 1 x 2MB
Std. 1 x 4MB
10+ years life
2
15
