13.3 Main Parts

Power Supply
(hidden)
CPU Board
Intermec EasyCoder 501 XP & 601 XP – Service Manual
This illustration shows the complete electronics compartment, but
with the Centronics interface board removed to improve the view
of the CPU board. There is no difference between the electronics
compartments of EasyCoder 501 XP and EasyCoder 601 XP.
Ribbon Supply Unit
Liner/Batch Takeup Motor
Chapter 13 Electronics Compartment
Ribbon Rewind Unit
Print Unit Stepper Motor
107
